8.4″ MRD1808-405 Dual RackMount COTS Color LCD Monitor, Active Buffered Loop-Thru Video

MRD1808-405 Dual Rack Mount 8.4-inch LCD monitor features three [3] RS170/RS343 Red-Green-Blue [RGB] BNC Video Inputs with buffered RGB Loop-through outputs. The Rugged MRD1808 series of Rack Mount LCD Monitors are designed specifically for COTS Military Display applications.

Occupying only 6 standard EIA RS310 D rack units on a 19” equipment rack, model MRD1808-405 features two high resolution 8.4” LCD screens with completely independent OSD controls and buffered RGB video inputs. Each 8.4-inch display of this Dual Rack Mount panel provides image reproduction that exceeds all other displays available in a similar form factor.

GET EZ QUOTE

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.

The MRD1808-405 series of Rugged Rack Mount LCD Monitors are designed specifically for COTS Military Display applications.  The MRD1808-405 occupies only 6 rack units of a standard EIA RS310 D – 19” equipment rack, yet has two high resolution 8.4” LCD screens with completely independent OSD controls and video inputs. The MRD1808-405 provides image reproduction that exceeds all other displays available in a similar form factor. The MRD1808-405 operates operating with legacy RGB signal timings such as RS-170 (525 Line) and RS-343 (875-Line) Interlace formats. Each 8.4" LCD display accepts analog RS-170 and RS-343 format Video input signals on 3 BNC connectors and provides 3 Buffered Unity-Gain BNC Outputs for loop-through operations to other display devices. With their rugged construction and -30°C to +85°C Extended Operating Temperature Ratings, Dynamic Displays' sturdy rackmount LCD monitors are used in many military, industrial, manufacturing, transportation applications, and other uses that require bright, crisp images and versatile signal interfaces in severe environments. For an Industrial-grade version of this product, see QES1508-405
Brochure
2D Drawing
3D Drawing
Contact Us

MRD1808-405 Series Features

  • 8.4 In SVGA TFT LCD Display with Solid State LED Backlight.
  • 800 x 600 Native Resolution.
  • High Contrast: 1000:1 Typical.
  • High Bright TFT Display: 600 Nits.
  • Wide Viewing Angle: 80R/80L – 80U/60L.
  • Bonded Anti-Glare Protective Faceplate Glass for Superior Optical Performance and Enhance Protection on Extreme Environments.
  • RS-170 (525 Line) & RS-343 (875-Line) Interlace Formats.
  • Analog RGB Sync On Green (SOG) -3 BNC.
  • 15.75 to 100 KHz -Specially designed for Slow Scan Signals - Legacy Timings.
  • 3 Buffered Unity-Gain BNC Outputs (RGB).
  • 90-264VAC Auto Ranging Internal AC Power Supply.
  • Aspect Ratio: 1:1 or 4:3 (OSD Selection).
  • Extended Operating Temperature Rating: -30°C to +85°C.
  • Convenient Front Controls.
  • Internal Ruggedized Construction.
  • Conformal Coating of Internal Assemblies for Enhanced Ruggedness.
  • Rugged Industrial-Grade Steel Chassis.
  • Heavy Duty Aluminum Front Bezel.
  • Heavy Duty Cold Roll Steel Chassis.
  • EIA RS310 D – 19” Rack Mount Standard.
  • Front Mounted Handles.

Other Options Include

  • Custom designs including spec, color, finish, and format.
  • Designed, Engineered and Built to comply with Military Standards.
  • NVIS Class A & B.
  • NTSC/PAL Composite Video (RCA Jack) and S-Video (4 Pin Mini-Din).
  • TTL Video Input for EGA, CGA and MDA Timings.
  • 12VDC, 24VDC, 28VDC, and 48VDCInput Voltage.
  • 91 Ohm Video Termination.
  • Front Manual Full Range Brightness and Contrast Control (Dimming).
  • High Brightness TFT LCD Option – 1,000 Nits.
  • Touch Screen: Resistive, Capacitive, and SAW.
  • Wireless Remote Control.
