Dynamic Displays QES1020-209,
20 In Color CRT Display Replacement

Model QES1519-235 19 In LCD replaces Dynamic Displays, Inc. QES1020-209, 20 In Color CRT Monitor used in Dynamic Displays Slow-scan Autosync.

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.

Dynamic Displays offers a full line of compatible replacement Industrial for CRT monitor display systems for Aydin and Vartech Industrial Displays. Please contact Dynamic Displays for replacement of the following Monitors:
  • Aydin 8834
  • Aydin 8835
  • Aydin 8939
  • Aydin 9003
  • Aydin 9008R
  • Aydin 9008RX
  • Aydin Patriot 8830LP
  • Intecolor E02038-20F, RGB SOG, OF
  • Intecolor E20FB-222, RGB SOG open frame flat profile 20" CRT
  • Vartech VT20A-CH

QES1519-235 Series Features

  • Drop directly into the mounting holes of the a 20” CRT Monitor
  • Replaces QES1519-202 Alma2000 control, 20" RGB CRT, 15.75 kHz
  • 19.0” Color SXGA TFT LCD with LED Backlight Module
  • 15.75 to 100 KHz Legacy Timings
  • Analog RGB Sync On Green Capable
  • 5 BNC Input (RGB)
  • Heavy Duty Aluminum Front Bezel
  • Heavy Duty Cold Roll Steel Chassis
  • RCA (NTSC/PAL) and 5 Pin Mini Din (S-video)
  • RS170 - RS343 Video Input

Other Options Include

  • Touch Screen: Resistive, Capacitive and SAW
  • TTL Input Option for EGA, CGA and MDA
  • Wireless Remote Control
