Sony Model SCC-572B-A 9 In Color CRT Monitor replacement

Model QES1508-108 8.4-inch LCD replaces Sony Model SCC-572B-A 9″ TTL color CRT monitors in Burny 5 CNC Controls.

---

Model QES1508-108 8.4-inch LCD replaces Sony Model SCC-572B-A 9" TTL color CRT monitors in Burny 5 CNC Controls.

If the Sony Model SCC-572B-A 9" monochrome CRT monitor in your Burny 5 CNC Control has failed or simply need replacing, you now have options. You no longer need to rely on refurbished old CRT replacements or cheap Chinese displays with unknown warranties and no support. You no longer need to worry about splicing wires and changing connectors. Dynamic Displays QES1508-108 8.4-inch LCD is the simple, reliable, cost-effective, easy-to-install CRT replacement you are looking for. Proudly manufactured in America's heartland and backed by a 2-year factory warranty and bi-lingual (English / Spanish) customer support, Dynamic Displays' Model QES1508-108 8.4-inch LCD is a direct replacement for the Sony Model SCC-572B-A 9-inch CRT display used in your Burny 5 CNC Control. Model QES1508-108 8.4 inch LCD has the same 8-pin Burndy video input format and 110/220 VAC power as your old Sony Model SCC-572B-A 9-inch CRT display and with its long life (>50,000 hours) LCD backlight this LCD will provide crisp, bright images for years to come.

Installing model QES1508-108 LCD into your Burny 5 CNC control:

You can install the QES1508-108 8.4-inch LCD monitor into your existing Sony SCC-572B-A's monitor chassis with just a few easy steps.

• First, disconnect the AC power and the 8-pin Burndy video connection and remove the 9-inch CRT chassis from your Burny 5 machine control.
• Second, remove the old 9-inch CRT and electronics from the Sony SCC-572B-A'schassis.
• Third, mount the QES1508-108 8.4-inch LCD into the now-empty 9-inch CRT mounting holes.
• Fourth, re-install the 9-inch CRT chassis into your Burny 5 CNC control.
• Finally, re-attach the the 8-pin Burndy video cable and the AC power connections.

The installation is complete. All you need do next is power your equipment up and see the bright clear images now displayed. The LCD will auto-adjust to present the correct image. If the LCD needs further adjustment, we've provided on-screen-display adjustment capability. The long life (>50,000 hours) LCD backlight in the rugged, high-performance 8.4-inch Active Matrix Color TFT LCD will provide crisp, clear images for years to come. on't delay. Upgrade the low-performance Sony Model SCC-572B-A 9-inch CRT display in your Burny 5 control with a new, reliable QES1508-108 LCD Flat Panel display today and extend the useful life of your CNC shape cutting equipment for years to come. Please also consider Dynamic Displays' many industrial LCD products for your other CNC monitor replacement needs

The Dynamic Displays Advantage

• Made in the USA: Our products are designed and manufactured in Eau Claire, WI, USA.
• Our products include a 2-year warranty.
• 100% satisfaction guaranteed.
• Proud and proven: We have been in business since 1991 as an industrial manufacturer with a proven, tangible track record.
• Human interface: Our bilingual (English/Spanish) technical support staff is highly responsive and based in the United States

Equivalent Models: Kristel C72314
