Rugged MRD1810 Sseries COTS 10.4" LCD Display meets MIL-SPEC Requirements - Front View Text.

10.4″ MRD1810C-PM Panel Mount Series, Rugged COTS LCD Display

Though rugged enough for most Land-based and Shipboard Applications, the MRD1810C-PM 10.4” rugged LCD is versatile, as well.  With provisions for Color or Monochrome factory setup Inputs and RS170 / RS343 Video Operation, the MRD-1810 COTS LCD Monitors allow for easy insertion into legacy technologies and reduces obsolescence risks.

Though rugged enough for most Land-based vehicle and Shipboard Applications, the MRD-1810 10.4” rugged LCD is versatile, as well.

GET EZ QUOTE

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.

Though rugged enough for most Land-based vehicle and Shipboard Applications, Dynamic Displays' Rugged 10.4-inch MRD1810C-PM Panel Mount LCD display is versatile, as well. With provisions for Color or Monochrome Inputs and RS170 / RS343 Video Operation, the MRD1810C-PM COTS 10.4 inch LCD Monitors provides easy insertion into legacy technologies and reduces obsolescence risks. Our Military Rugged Displays (MRD) are designed with rigorous shock and vibration safeguards, high moisture safeguards, provisions for extreme temperature operation, as well as Electromagnetic Environmental Interference protection for use in extremely harsh weather conditions found in many Military Applications. These premium displays accept the analog monochrome RS-170 and RS-343 Video input signal format on a single BNC and feature differential input capability for high common-mode noise rejection for greatly increased electronic noise immunity and reduced electronic emissions. Target application platforms for the MRD-1810 Series COTS Military LCD Display include: Aircraft Simulator Displays, Ground Vehicles, and Mobile Shelters, Military & Aerospace Displays, Surface Ships, US Navy Aircraft Traffic, US Navy AN-UYQ-70 Tactical Workstation.
10.4 In MIL-SPEC COTS Rugged LCD Display - Rear View.
10.4 In MIL-SPEC COTS Rugged LCD Display - Rear View.
Brochure
2D Drawing
3D Drawing
Contact Us

MRD1810C-PM Series Features

  • 10.4 In SVGA TFT LCD Display with Solid State LED Backlight.
  • 800 x 600 Native Resolution.
  • High Contrast: 700:1 Typical.
  • High Bright TFT Display: 1500 Nits.
  • Wide Viewing Angle: 80R/80L – 60U/80L.
  • Bonded Anti-Glare Protective Faceplate Glass for Superior Optical Performance and Enhance Protection on Extreme Environments.
  • RS-170 (525 Line) & RS-343 (875-Line) Interlace Formats.
  • Analog Sync On Green (SOG) - Composite Sync.
  • Color or Monochrome Operation - Factory Setup.
  • 90-264VAC Auto Ranging Internal AC Power Supply.
  • Aspect Ratio: 1:1 or 4:3 (OSD Selection).
  • Front Manual Full Range Brightness and Contrast Control (Dimming).
  • Full-Range Dimming to Black.
  • Extended Operating Temperature Rating: -30°C to +85°C.
  • Convenient Front Controls.
  • Internal Ruggedized Construction.
  • Conformal Coating of Internal Assemblies for Enhanced Ruggedness.
  • Rugged Industrial-Grade Steel Chassis.
  • Heavy Duty Aluminum Front Bezel.
  • Heavy Duty Cold Roll Steel Chassis.
  • NEMA 4/12 & IP65 Front Panel – Panel Mount.
  • Custom Designs Based on Customer’s Exact Needs.

Other Options Include

  • Custom Designs Available; Including Spec, Color, Finish and Format.
  • 12VDC, 24VDC, 28VDC, and 48VDCInput Voltage.
  • NTSC/PAL Composite Video.
  • Differential Monochrome Video Input for Enhanced Noise Immunity.
  • 91 Ohm Video Termination.
  • Sun Light Readable.
  • Touch Screen: Resistive, Capacitive, and SAW.
  • Wireless Remote Control.
