Fuji CDC-1230,
12 In Color CRT Monitor Replacement

Model QES1510-023 10.4 In LCD replaces Fuji CDC-1230, 12 In Color CRT Monitors used in T4124A.

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.


Industrial Panels offers a cost-effective 10.4” LCD monitor replacement for Legacy CNC monitor use on Industrial Control Equipment such as CNC Controls MachineLathe Controls, Factory Automation, and Process Control.  The QES1510-023 model drops directly into the mounting holes of the original Control Panel monitor. Designed to replace the original monitor on the following equipment:

  • Boehringer VDF 250 CNC with Philips B2T Control
  • Fuji CDC-1230
  • Heidenhain  BE411 Monitor – Control System TNC155
  • Heidenhain BE211 - Control System TNC151
  • Heidenhain BE211B - Control System TNC151B
  • KME 26C12F22BX
  • KME 27S12DMA01
  • Matsushita TX-1207AA
  • Mitsubishi C3240LP
  • Okuma OSP7000M-SC / OSP7000M-S - Monitor CDM-122R1 (by Toei Electronics)
  • Siemens 820 control - Monitor SC 1200

This LCD replacement monitor, model QES1510-023 has a rugged steel chassis and is designed to drop into the mounting frame of the Industrial Control Equipment Monitor Console.  In addition, this new 10.4” LCD monitor has mating video and power input connections, circuitry and firmware engineered specifically for plug and play install into these legacies CNC Operator Interface.  We guarantee it will work in your old control. For the past several years, Industrial Panels have concentrated on designing and producing LCD Replacement Monitors for obsolete and hard-to-find legacy CRT monitors and Industrial Monitors.  Drawing on 25 years experience of in manufacturing CRT displays for the OEM market place, we have developed and produces LCD display solutions for a wide range of CNC Machine Tools, Factory Automation, Process Controls and other legacy manufacturing systems.

Equivalent Model Numbers: Boehringer VDF250, Heidenhain  BE 411, Heidenhain BE 211, Heidenhain BE 211B, Heidenhain Control System TNC 151, Heidenhain Control System TNC 151B, Heidenhain Control System TNC 155, KME 26C12F22BX, KME 27S12DMA01, Matsushita TX1207AA, Mitsubishi C 3240LP, Siemens Monitor SC1200, Toei Electronics CDM122R1

QES1510-023 Series Features

  • 15.75 to 100 KHz -Specially designed for Slow Scan Signals - Legacy CRT Monitors
  • TTL Video Input for EGA, CGA and MDA
  • Drop directly into the mounting holes of the a 12” CRT Monitor
  • DB-9 Pin Input video
  • 10.4” TFT-LCD Display with LED backlight
  • Power Requirements: 110 / 220VAC or 12VDC @ 1Amp
