Allen Bradley 8000-XLCVD
(PN 958671-02),
12 In Color CRT Display Replacement

Model QES1510-025 10.4 In LCD replaces 8000-XLCVD, 8000XLCVD, or PN 958671-02 – 12 In Color CRT Displays used in Allen Bradley 8400 MP CNC Machine.

At Dynamic Displays we are dedicated to speed & honesty with our EZ-Quote system.


Drawing on over 20 years experience of manufacturing rugged displays for the OEM industrial market place, Dynamic Displays has developed LCD display solutions for a wide range of CNC Machine Tools, Factory Automation, Process Controls and other legacy manufacturing systems.  Our rugged, industrial-grade QES1510-025 open frame display employs a high resolution Active 10.4" Matrix color LCD with a viewable screen area comparable with any 12" CRT. No matter how old, or complicated, the CRT monitor in your CNC machine might seem to you, we assure you that we have a worry-free replacement LCD monitor.

In our QES1510-025 10" Color LCD, we’ve incorporated the latest microprocessor controlled A/D boards with a HEX file specifically programmed to ensure compatibility with the Allen Bradley 8400MP system video signals. The painstaking effort to correctly match our LCD monitor model to the Allen Bradley OEM video signal results in a bright, sharp, crisp image for your CNC control system.

Now, Dynamic Displays, Inc. offers an economical 10.4" LCD monitor replacement for the obsolete Toshiba D12CX73 12" CRT monitor in the Allen Bradley 8400MP Control.

Our model QES1510-025 LCD monitor has a rugged steel chassis designed to drop into the mounting holes of the original 8000-XLCVD (PN 958671-02) CRT Monitor. This new 10.4" LCD monitor has mating video and power input connections and with circuitry and firmware engineered specifically to work in your legacy Allen Bradley 8400 MP control.

Allen Bradley 8000-XLCVD: HRS 8 Pin Input Signal Connector Option.

Allen Bradley 8000-XLCVD: HRS 8 Pin Input Signal Connector Option.


Allen Bradley 8000-XLCVD: 15 Pin LD DSub Input Signal Connector Option.

Allen Bradley 8000-XLCVD: 15 Pin LD DSub Input Signal Connector Option.

Direct Drop in LCD replacement display for:
  • Allen Bradley 8400MP 12" CRT Monitors
  • Allen Bradley 9/Series CNC Systems - 12" CRT Monitors
  • Allen Bradley 958671-02 12" Color CRT display
  • Toshiba D12CX73 12" Color CRT monitor

QES1510-025 Series Features

  • Designed For Allen Bradley 8400MP Series CNC Control Panels
  • Drop in LCD replacement display for Allen Bradley 958671-02 12" Color CRT display
  • Drop in LCD replacement display for Toshiba D12CX73 12" Color CRT monitor
  • Rugged steel chassis drops directly into the mounting holes of the 12” color CRT
  • 10.4 inch SVGA Color TFT LCD with reliable solid state LED Backlight
  • TTL video Input - Allen Bradley 8400MP system video signals
  • High Contrast – 500:1 Typical
  • Universal Power Supply with VESA Power Management
  • Power Requirements: 100-240 VAC 50-60 Hz @ 1 Amp
  • Dimensions: 11.2 ” (H) x 8.83 ” (W) Kit Only

Other Options Include

  • Anti-Reflective Protective Faceplate option
  • Strengthened Glass Protection Option
  • Wireless Remote Control Option
